#50 SLIDER WITH TRIAXIAL JOINT
HS Mast Slider System - Size 50
Share THIS PAGE:

HS Mast Slider System - Size 50

For Boats Up To 52 ft (16m)

Availability: Make a selection

Sku# Make a selection
Item ID Make a selection
Mfg# Make a selection
SELECT PRODUCT OPTIONS
Please choose product option(s).
Overview
The Antal HS Mast Slider System is designed for boats with full batten mainsails that experience high loads and compression-loading on the mainsail luff. The system’s aluminium sliders contain HS composite fiber inserts that run on an aluminium track mounted on the mast. The material is made from special resins strengthened with fiber and is self lubricating.
• Three systems available: 601.121 requires drilling and tapping the spar, 601.131 and 601.141 are designed to me mounted with slugs, 131 is for vertical mounting and 141 is for horizontal mounting
• Track is designed to be installed when the mast is veritical
• HS composite fiber is a new material that is durable over long periods of use
• Properies of HS material allow the cars to be shorter than standard ball-bearing car systems
• Minimum friction under load
• Less maintenance than ball bearing car systems
• Cars can easily be removed and re-installed on the track whenever the mainsail is changed

PRODUCT DETAILS TABLE WITH OPTIONS AND PRICING
Click on See detailed table of all productsto see specifications of product options.
Add To Cart
Sku#Item IDAntal Marine Hardware#AvailabilityDescriptionUOMYour PriceQTY
85306ANL 692.411 692.411Loading...HS Mast Slider System - Size 50, End FittingLoading...
85309ANL 610.421 610.421Loading...HS Mast Slider System - Size 50, Double HeadboardLoading...
85310ANL 630.411 630.411Loading...HS Mast Slider System - Size 50, Single HeadboardLoading...
85308ANL 614.411 614.411Loading...HS Mast Slider System - Size 50, Simple SliderLoading...
85307ANL 610.401 610.401Loading...HS Mast Slider System - Size 50, Slider With JointLoading...
85305ANL 690.421 690.421Loading...HS Mast Slider System - Size 50, Track JointLoading...
85317ANL 602.421 602.421Loading...HS Mast Slider System - Size 50, LoaderLoading...
85303ANL 601.200 601.200Loading...HS Mast Slider System - Size 50, Installation ToolLoading...
Add To Cart
