• Cycles On-Off when load is excessive
• Breaker type: type I
• Voltage: 6-12VDC
• Amperes: 50A
• Terminals: two threaded studs with nuts
• Terminal size: 10-32 thread
• Housing style: plated steel case with bracket
• Mounting method: with bracket attached along the case
• Overall part dimensions: 2"(50.80mm)L x .78"(19.81mm)W x 1.380"(35.05mm)H
• Mounting hole distance (on center): 1.56"(39.62 mm)
• Mounting hole dia: .218"(5.55mm)

Specifications

MFG #:30055-50-BX
