Wire Rope Sheaves

Series 624 • Aluminum or Bronze • Available in 3" to 12"

Availability: Make a selection

Sku# Make a selection
Item ID Make a selection
Mfg# Make a selection
SELECT PRODUCT OPTIONS
Please choose product option(s).
Overview
In addition to their use in chain and wire steering systems, Edson sheaves are used in many other boat building applications — centerboards, custom deck hardware, remote actuators for emergency shut-off valves, CO₂, etc.

Care should be taken to ensure that the wire and sheave diameter are matched.
ABYC and CE standards require sheave diameters to be a minimum of 16 times the diameter of the wire.
However, for optimum performance, use the largest sheave practical to prevent wire jump-out and to reduce friction.

Aluminum sheaves are ideal for applications which require light weight and sensitivity - such as performance and racing boats.
Bronze sheaves are suggested for heavy duty or long-term cruising applications.
Sheave hubs are wider than the rims to prevent side friction and noise.

PRODUCT DETAILS TABLE WITH OPTIONS AND PRICING
Click on See detailed table of all productsto see specifications of product options.
Add To Cart
Sku#Item IDEdson Marine#AvailabilityDescriptionUOMYour PriceQTY
209597EDS 624AL-6ALNB 624AL-6ALNBLoading...6" Aluminum Sheave - 3/8" Wire, SS Needle BearingLoading...
162458EDS 624BR-3BR 624BR-3BRLoading...3" Bronze Sheave - 3/16" Wire, Bronze Oilite BearingLoading...
159865EDS 624BR-4BR 624BR-4BRLoading...4" Bronze Sheave - 1/4" Wire, Bronze Oilite BearingLoading...
368730EDS 624AL-8ALNB 624AL-8ALNBLoading...8" Aluminum Sheave - 1/2" Wire, SS Needle BearingLoading...
167472EDS 624AL-4AL 624AL-4ALLoading...4" Aluminum Sheave - 1/4" Wire, Bronze Oilite BearingLoading...
209335EDS 624-6AL 624-6ALLoading...6" Aluminum Sheave - 3/8" Wire, SS Needle BearingLoading...
