Advanced Automatic Charging Relay - Dual Battery

• Supports Multiple Engine Installations with Dual Start/Engine Isolation Inputs
• Start Assist Option for Auto or Manual Connection with Start / Aux Batteries
• Optional Priority Charging Delays Closure Until Charging Battery is More Charged
• Optional Aux Battery Priority Shares Start Battery Energy, Maintains Starting Ability
• Optional Low Voltage Lockout Protects From Connecting Into Shorted Cell Battery
• Eliminates Dead Start Batteries by sharing charging on either of two batteries and isolating batteries when no charge sources are present.
• Simple & Robust Installation: Integrated sealed plug eliminates corrosion, includes Deutsch/Amphenol DTM connector harness
• Additional Low Amp Output can be used to report device status remotely.
• Bullet-proof Construction: Sealed unit, high temperature materials allow mounting anywhere. Integrated thermal overload shutdown protection.
• Ultra Low Off-State Current: Compare to typical ACRs (7-10 mA) vs 7610 ACR @ 1.3 mA
• Adjustable On and Off Voltage Settngs allow sharing start battery energy for auxiliary battery while ensuring engine starting ability; or charging start battery before sharing with auxiliary
• Dual Start/Engine Isolation input option for protectting sensitive electronics or isolating multiple charging sources to optimize overall system performance.
• Start Assist input option to ensure maximum cranking amps available.
• 4 Year Industry Leading Warranty
