Description
Compact voltage sensing relay for battery charge management.
This Mini Automatic Charging Relay (M-ACR) is designed to manage the charging current from alternators up to 65 Amps found on most outboards and many inboard engines to 2 battery banks.
Automatically manages charging and isolation of battery banks, ensuring that connected auxiliary loads will not deplete the starting battery to prevent engine starting.
Auto sensing for both 12V and 24V systems.
Remote and local LED indicators; panel or surface mounting.
Protects electronics from voltage sags and spikes.
Start isolation feature protects sensitive digital electronics with stored memory settings by temporarily isolating house loads from the engine starting circuit during engine cranking.
The compact design allows for three mounting styles: surface, rear, or panel mount.
Features —
• Senses charging on two battery banks (such as start and house)
• Pull off and snap on insulating cover
• LED indicates ACR status
• Ignition protected ISO8846 / SAE J1171
• 1/4" x 0.032" male quick connect terminal for ground
• 1/4" terminal studs
• 7/16" (11 mm) stud length to accept multiple cable terminals
• Waterproof – rated IP67 for temporary immersion
• CE marked
