• 500 Amp Continuous Capability / Extremely Compact Footprint
• Available With or Without Intuitive Front Facing Manual Override Knob with Ability to Lock Device ON or OFF for Servicing
• Fully Adjustable Open and Close Voltage Set Points Support All Battery Types
• Supports Single/Multiple Engine Installations with Dual Start/Engine Isolation Inputs
• Remote ON/OFF Input Allows Combining Batteries During Hard Start Events or Forcing Isolation of Batteries During Engine Starts.
• Optional Priority Charging Delays Closure Until Charging Battery is More Charged
• Optional Aux Battery Priority Shares Start Battery Energy, Maintains Starting Ability
• Eliminates Dead Start Batteries by sharing charging on either of two batteries and isolating batteries when no charge sources are present.
• Simple & Robust Installation: Integrated sealed plug eliminates corrosion, includes Deutsch DT/AT connector harness
• Additional Low Amp Output can be used to report device status remotely or synchronize with external devices
• Bullet-proof Construction: Sealed to IP67/ IP6K9K, high temperature materials allow mounting anywhere.
• 90% Less Off-State Current: Compared to competition (13 mA) vs 8701 ACR @ 1.3 mA
• Adjustable On and Off Voltage Settings allow sharing start battery energy for auxiliary battery while ensuring engine starting ability; or charging start battery before sharing with auxiliary
• Dual Start/Engine Isolation input option for protecting sensitive electronics or isolating multiple charging sources to optimize overall system performance.
• Start Assist input option helps ensure maximum cranking amps available.
• See linked tech document for detailed specs and schematics
