A200 Class A AIS Transceiver with Color Screen

The A200 Series integrates sophisticated AIS capabilities with user-friendly design to facilitate mission-critical operations across various environments.

Whether navigating coastal waters or inland channels, the A200 Series guarantees dependable, secure, and fully compliant vessel tracking and communication.

Equipped with a high-definition color display and options for encrypted blue light services, it offers clear and secure situational awareness. Its advanced and distinctive features, including real-time alerts, target filtering, extensive vessel information lists, and live weather updates, empower crews to make prompt and informed decisions with confidence.

Designed for reliability, clarity, and control, the A200 Series is the AIS system that professionals around the globe trust.

The A200 Series provides strong, compliant AIS performance on a worldwide scale. Fully certified for both SOLAS and Inland Waterway applications, it adheres to the highest international standards for safety and navigation.

• IMO SOLAS certified AIS Class A
• EU Inland Waterway certified ruggedized and impervious to extreme environments - water (IPx6, IPx7), dampness, shock, vibration, and temperatures
• High performance latest generation GPS
• Suitable internal or permanent external installation
• Robust ergonomic button and rotary-knob user interfaces with configurable multi-lingual menu options
• Integrated high-definition color display with night mode
• ENC chart (C-Map) with configurable AIS target overlay
• Silent mode - AIS transmissions are stopped, all AIS messages continue to be received
• Integrated WiFi
• Pilot plug cable and junction box accessory options

Specifications:
• Operating temperature: -13° to 131° F (-25° to 55° C)
• Ingress protection: IPx6 and IPx7
• 12V or 24V DC
• Average current (at 12V): 520mA
• Peak current: 6A
• Average power consumption (at 12V): 6.2W
• Galvanic isolation: NMEA 0183, NMEA 2000, power supply, VHF antenna port
• Power: 2-way circular multipole
• Systems supported: GPS, GLONASS, BeiDou, Galileo (two of any combination, three including GPS, Galileo)
• Channels: 72
• Internal/external antenna: External only
• Time to first fix from a cold start: 26s
• VDL access scheme: SOTDMA
• Operating frequency: 156.025MHz - 162.025MHz
• Channel bandwidth: 25kHz
• Receivers/transmitters: 3 x receivers, 1 x transmitter
• AIS receiver sensitivity (20% PER): -111 dBm
• AIS transmitter power: 12W (+41 dBm)
• SD card interface: Micro SD card interface for logging and chart cards (not available from Em-Trak)
• GNSS Antenna Mounting: 1" 14 TPI pole mount required
• 6"H x 6.5"W x 3.7"D (152 x 165 x 95 mm)
• 2.4 lbs (1.1 kg)
