Precision-9 Compass

A solid-state compass that provides heading, rate of turn, pitch, and roll output via NMEA 2000®.
• Heading, Rate Of Turn (ROT), pitch and roll output over NMEA 2000®
• Accurate and reliable solid-state sensor technology
• Heading accuracy of ±2° after calibration
• Easily adjustable mounting bracket allows bulkhead or up-mast installation
• IPX7 waterproof for external up-mast mounting on steel hulled vessels
• Simple installation with a single NMEA 2000® connection
• N2K PG Ns: 127250, 127251, 127257, 127252
• NMEA 2000 Connectivity: 1x NMEA 2000 Micro-C port, 1 LEN
• Power Consumption max: 0,4W (N2K Load 1 len)
• 12V DC (8-16V DC) via NMEA2000
• Operating Temperature Range: -25 to + 65ºC (-13 to + 149ºF)
• Storage Temperature Range: -30 to + 70ºC (-22 to + 158ºF)
• IPx7 Waterproofrating
• Heading Sensor Accuracy: +/-2deg. After calibration
• Heading Sensor Data Available: Magnetic heading, rate of turn, pitch/roll, heave
• Solid state, rate stabilized
• Compass Safe: 500mm (1,7")
• 1.42"W x 4.69"H x 4.69"D
• Bracket, Bulkhead Mounting
