Maretron Fuel Flow Sensors
Maretron Fuel Flow Sensor, M1AR - 2 LPH to 100 LPH (0.53 GPH to 26.4 GPH)
SKU: 1015418 Item ID: MRT M1AR
- For use with FFM100
Description
When fluid passes through the sensor, the rotors turn. Magnets which are located in the rotors will pass across sensors in the sensor circuit board. Pulses from these sensors are transmitted to the FFM100 which performs flow rate calculations based on the received pulses.
Specifications
MFG #:M1AR
| Unit - Flow RangeM1AR - 2 LPH to 100 LPH (0.53 GPH to 26.4 GPH)
Unit
M1AR
Flow Range
2 LPH to 100 LPH (0.53 GPH to 26.4 GPH)
Nominal K Factor
1000 Pulses/L (3785.4 Pulses/G)
Operating Temp
-40°C to 80°C (-40°F to 176°F)
Storage Temp
-65°C to 170°C (-85°F to 338°F)
Port Size
1/4" NPT Female
Housing Material
Aluminum
Rotor Material
PPS (Ryton)
Shaft Material
316/304 Stainless Steel
Magnet Material
Samarian Cobalt
O-ring Material
FKM (Viton)
Accuracy % Reading
±0.25%
Max Viscosity
1000 cPs
Max Operating Pressure
68.95 Bar (1000 PSI)
Strainer Size
200 Mesh
Cable Length
1m (3.28 ft)
Weight
775g (1.71 lb)
Dimensions
75 x 71 x 48.6 mm (2.9" x 2.8" x 1.9")
