Turbine 900 / 1000 Series Electric Primer Pump Kit - 24V

The Fuel Primer Pump Kit is an innovative and proprietary system consisting of a pre-screen filter, a flow bypass circuit and a pump powered by a 12V DC brushed motor or a 24V DC brushless motor.

When the switch is activated the fuel is drawn into the pre-screen and then pumped through the housing refilling the unit with fuel.

When not in use the primer pump system is bypassed and the Racor fuel filter/water separator functions normally.

The Primer Pump Kit works on Racor duplex and triplex systems also. This will allow one Racor primer pump to prime the other filter or filters in a manifold system such as a 751000MAX for example.

Product Features –
• Easy installation
• Pump adds only 3.3” to the over all assembly
• 60 gallons per hour flow rate while in priming mode
• 12V DC model has a brushed electric motor
• 24V DC model has a brushless electric motor
• 100 micron pre-screen
• One size fits several models
• Kit includes wiring harness and controller switch
• Allows for electric re-priming of filter and fuel system
• Not for continuous duty use
