Schaefer's largest furler, System 4100 has the engineered-in strength to handle very heavy furling loads. Huge, 1/2" Torlon™ bearings are combined with a powerful, large diameter drum to provide efficient, rugged furling for the largest headsails. This tough,winchable design is an affordable alternative to the high costs associated with hydraulic or electric systems.
• Wire Sizes: 7/16", 1/2", 9/16"
• Rod Sizes: -30, -40
• Pin Sizes: 3/4", 7/8", 1"
• 78' 9-1/4" provided system length
• (10) 7' round, twin groove accepts #6 luff tape
• 1/2" Torlon™ Bearings (78 in triple race upper swivel, 60 in triple race drum)
• Drum design: open/split, 6" diameter drum holds up to 98' of 1/2" line
• Weight: 72 lbs. packaged furler, 67 lbs. packaged extrusions
