- Inboard or outboard
- Hydraulic steering systems
- Super efficient steering
Your Price:$1,293.97/ Each
Availability:
1 Remaining In Stock
Ships immediately
Description
Teleflex helms are very popular offering smooth, super efficient steering designed for inboards or outboards on boats up to 50' or high performance hulls with single or multiple outboards up to 600 HP combined.
Capilano Helms are engineered and manufactured for heavy duty marine usage, and are suitable for commercial, work boat and pleasure boat applications. Capilano Hydraulic Steering has been designed to meet ABS, Lloyds and DNV specifications. For all Pleasure and Work Boat applications 38ft. (11.5m) and smaller with some exceptions, please refer to the SeaStar range of Inboard Steering Systems.
Features:
• Easy installation for single and dual rudder vessels
• Two axis articulation
• Easy autopilot interface
Specifications
MFG #:HH5250
| Displacement - Cu In- Rev1.7 - 3.4
| Volts1250
Type
Capilano - 1250V - 1.7/3.4 in³
Mount Type
Rear
Disp. CU.IN/REV
1.7 - 3.4
Disp. CC/REV
27.8 - 55.7
Relief Valve PSI
1000
Relief Valve BAR
70
Volts
1250
Warning
This item may be known to the State of California to cause cancer, birth defects, or other reproductive harm.
Barcodes
731957803436
HH5250
HH5250
