e-Panel 2P - Control Panel w/ Timed Alarm Mute

On/Off Control Panel with Mute | 100% Waterproof Panel

Availability: Make a selection

Sku# Make a selection
Item ID Make a selection
Mfg# Make a selection
SELECT PRODUCT OPTIONS
Please choose product option(s).
Overview
Captains and crew want the ability to mute an audible alarm during an equipment malfunction or emergency. However, there is concern that the mute feature will accidentally be left on, rendering the audible alarm inactive — even though an alarm condition may still exist.
The e-Panel P series with Inteli-mute is the answer. Inteli-Mute eliminates the possibility of the mute button being "accidentally" activated and forgotten about by monitoring the alarm state and reminding you periodically that the mute switch is still active.

The e-panel 2P On/Off Series is an alarm/monitor panel which is connected to a device such as a bilge blower.
The panel sounds a continuous alarm if the blower runs for more than 2 mintues -- signalling that the blower is still running. (Over two minutes of running is the built-in time limit the panel considers an "alarm condition".) The alarm sounds as long as the blower continues to operate.

Pushing the mute button on the panel silences the alarm, but leaves the back-lit Mute button flashing as a visual reminder that the device is still running.

After 5 minutes, Inteli-Mute checks to see if the device is still operating. If so, Inteli-Mute reactivates the audible alarm, warning you that an alarm condition is still present and needs to be resolved.

If after 5 minutes when Inteli-Mute checks for an alarm condition, there is no alarm condition or the alarm condition has been resolved, Inteli-Mute resets the panel to the "Ready" mode to wait for the next alert.

• Includes panel-mounted ATO fuse
• 20 Amp sealed 2-way switch

Manufacturer Resources

PRODUCT DETAILS TABLE WITH OPTIONS AND PRICING
Click on See detailed table of all productsto see specifications of product options.
Add To Cart
Sku#Item IDWater Witch#AvailabilityDescriptionUOMYour PriceQTY
167352WIT EPANEL2P-BLACK EPANEL2P-BLACKLoading...e-Panel 2P Series - 5 Min. Timed Alarm Mute Switch, Black - with On/Off Rocker SwitchLoading...
167353WIT EPANEL2P-WHITE EPANEL2P-WHITELoading...e-Panel 2P Series - 5 Min. Timed Alarm Mute Switch, White - with On/Off Rocker SwitchLoading...
