• Water resistant fuse holders accept commonly available AGC (fast acting) and MDL (slow blow) glass fuses
• Installed switch is ON-OFF
• Countersunk mounting holes throughout
• Two-part polyurethane slate gray finish
• Water resistant Contura switches
• "ON" indicating LEDs embedded in switch
• Includes set of 60 small format common DC labels
• Compact labels minimize panel space requirements
• Designed for installations where height restrictions are present
• Watertight mounting gasket
• Mil-Spec chemical treatment via immersion to protect every surface detail from corrosion
• Detailed installation instructions and cutout template
• Voltage 12 or 24 VDC
• Switch rating 20 amperes @ 12 VDC, 15 amperes @ 24 VDC
• Switch LED amperage draw 18 milliamperes each
• Fuse holder rating 20 Amperes maximum
• Panel cumulative rating 45 amperes
• NOTE: Water resistant panel labels are not backlightable
