Ride Vessel Control Systems for Catamarans

Answering the Cat Call
While Catamarans offer some advantages, these boats are still susceptible to wave action and their unique hull designs can present several trade-offs such as flatter turns, increased yaw or bow steering, and porpoising motions at high speeds.

Optimized for Catamarans
Seakeeper Ride utilizes proprietary variable gain algorithms to optimize its performance on boats of all types and in all sea conditions without special tuning or calibration by the operator. Specific to catamarans, custom software takes catamarans’ unique performance characteristics into account, providing enhanced underway stabilization and enabling catamarans to naturally bank into turns much more like traditional monohull vessels.

Catamaran Installation
For installation on symmetrical and semi-symmetrical hulls, Seakeeper Ride controllers can be mounted on both inboard and outboard sections of each demihull. On asymmetrical hulls, Seakeeper Ride’s controller will be mounted on the outboard section only where there is available space.

How Seakeeper Ride controllers work
Seakeeper Ride controllers are mounted to your boat’s transom, below the waterline. Using custom, proprietary inertial sensing hardware and software, the system understands how the boat is behaving in all three axes and commands deployment of the rotary blades to counteract pitch, roll, and yaw. As the blades are deployed, they create lift at the transom, managing the vessel’s motion instantaneously.

Why it’s better
Wave motions can happen consistently or inconsistently, they can be big or small, and can come from any direction. Often, these motions occur in just milliseconds. Thanks to expert control software and hardware, Seakeeper Ride’s proprietary, rapid-deployment rotary blades make 100 adjustments every second to combat wave motions.
Nothing compares to the first-of-its-kind Vessel Attitude Control System, Seakeeper Ride, which can eliminate up to 70% pitch and roll underway.

Eliminate up to 70% pitch and roll underway
Nothing compares to the first-of-its-kind Vessel Attitude Control System, Seakeeper Ride, which can eliminate up to 70% pitch and roll underway. Our proprietary, rapid-deployment rotary blades make 100 adjustments every second to combat wave motions, providing unmatched performance.

Additional Features

Rapid Actuation
Rotary blades deploy at a rate of up to 300 mm per second, making 100 adjustments every second; enabled by power-dense rotary design that requires just 7-10 Amps for operation.

Full Underway Control
Controls all motions (pitch, roll, yaw) thanks to deployment speed and proprietary control software and hardware.

Intuitive
Predicts motion and responds instantaneously to eliminate them before they’re felt with no buttons to push nor adjustments to make, providing a boating experience you never imagined.

Reliable
Drivetrain is completely sealed in a dry and greased environment with no mechanical exposure to saltwater.

Simple Installation
Easily installed on most transoms, both in new and aftermarket boats.

User Interface
The user interface is compatible with select Garmin, Simrad, and Raymarine MFDs. MFDs are not included in Seakeeper Ride equipment.

Controller components
• Controller One full assembly of all parts below
• Rotary Blade Deploys in and out to build pressure on the seal plate to control vessel motions
• Seal Plate Supports the actuator and the lifting forces created by the controllers
• Rotary Actuator Physically drives the rotary blade in and out of the water
• Actuator Plate The foundation that holds the actuator and seal plate to the transom plate
• Wedge Pack A combination of wedges to angle the seal plate relative to the hull bottom
• Transom Plate Adhered to the transom to support the lifting forces created by the controllers


Boat Compatibility
• Fiberglass or aluminum hull
• Stepped or non-stepped hull 19-35 ft
• Cruising speed greater than 20 mph
• Equipped with a compatible MFD
